7.4.4 Light Duty Wall Winch

The light duty wall winch is a further design variation suitable for loads from 30kg to 500kg. The mechanism is self sustaining without the need for ratchet or pawl. The design permits the winch to be mounted so that the wire rope may be taken off the drum in any position parallel to the mounting. Rope drum storage capacities vary between 10 metres and 30 metres. (See Figure 7.4.4-1 )
